|Place of Origin:||Guangdong, China|
Payment & Shipping Terms:
|Minimum Order Quantity:||>=1 Units|
|Packaging Details:||1 unit per box|
|Supply Ability:||1000 Unit/Units per Week|
|Power Supply:||AC110/220V Internal Power Supply||Operating Temperature:||0℃ To 50℃|
|Transmission Speed:||10Gb/s||Transmission Mode:||Technical Indexes|
managed media converter,
fast ethernet media converter
2U media converter rack 14 slots media conveter rack
16 slots with strong management
*Support 10Base-T, 100Base-TX, 1000Base-T
*Meet standards IEEE802.3z, IEEE802.3u, IEEE802.3x andIEEE802.3ah
*With high performance auto-sensing exchanging chipsetmeeting industrial standard, securing steady and non-traffic jam datatransmission and exchanging
*Max.2046bytes packet at store-and-forward mode, Max. 9Kbytes packet at cut-through mode
*AUTO-MDIX at electrical port, convenient for the user
*low power consumption, low heat, standalone type with 10Wspecial communication power supply, chassis with dual redundant power supply
*Max safety power 100W to ensure the stable work of theequipments
*hot swap media converter( in card type) and managementcard
*Master-and-slavestructure, Max. Cascading chassis number is 4
*Thefailure of the management card wont influence the work of other modules.
*Supporting remote and local management
*Supportingprotocols like CONSOLE, WEB and SNMP
*Interfacefor management: RS232 Console Port (RJ45) and 10/100Mbps RJ-45 Ethernet port
*Complete systeminformation can be set up and displayed, including the name of the chassis,terrain information, IP address and the versions of the hardware and soft ware.
*The statusof 10/100M media converterswith IP113A/C/F/M chipsets canbe monitored and queried at the same chassis system.
*10/100/1000M media converter card support SFP,CWDM SFP, DWDM SFP and can also display its DDM function.
*Mediaconverter card supports protocols like Q-in-Q Double Tag VLAN, IEEE802.1q TagVLAN and IEEE802.3x Flow control
*Detailedinformation regarding power supply can be tracked including AC or DC, power andpresent working status.
*Real timedisplay of voltage and temperature on the cards of the media converters
*Each portat local or remote devices can be set up or tracked, including the connectingstatus, connecting speed, half/full duplex, port locked and LFP.
*With ratelimiting, any rate between 0Mbps and 100Mbps can be set at the basic frame of 32Kbps, and any rate between 0Mbps and 1000M bps can be set at the basic frameof 64Kbps
*SupportingLink Loopback test, precisely locating the failure, convenient for link test
*Remotepower off alarming, precisely distinguish remote failure
*With SNMP protocol,Trap Destination and Community Name and related right can be set up, real timereceive and display of alarming information in way of SNMP Trap, specialsupervising window, bumping alarming information.
*OfferingMIB files, convenient to be merged to the third partys software like Open viewand SNMPC
*Powerfulhistorical alarming and operating log information tracking and management function
*Flowstatistic and pre-alarming function, real-time display of the communicationstatus at each port
*supportEquipment remote-restart, system or module restart by management software
*Withgraded management mode (common user, super user and administrator), and useridentification function
*Reset tofactory set up or dip switch status are optional
*Supportingonline upgrading by FTP
*NMSsupports network device auto-detect and auto-adding
*Real-timedisplay of voltage and temperature on the chassis and the operating status ofhe fans
*Withcentralized management and Top tree, several chassis can be managed in the sameinterface at the same time; with grouping management any converter can be convenientlymanipulated among many converters
