Shenzhen Sopto Technology Co., Ltd

1m Dac Copper Cable , 100G QSFP28 Dac Cables Compliant With SFF-8431 MSA

Product Details:
Place of Origin: Guangdong, China
Brand Name: SOPTO
Certification: CE RoHS FCC
Model Number: SPH-QSFP28-C1-30
Payment & Shipping Terms:
Minimum Order Quantity: 10 Piece/Pieces
Price: $74.00 - $77.00 / Piece
Packaging Details: 1 pcs per plastic bag
Supply Ability: 2000 Piece/Pieces per Month
  • Detail Information
  • Product Description

Detail Information

Data Rate: 100G Product Name: High-speed Cable
Warranty: 1 Year Operating Temperature: 0~70
Length: 1 M Keywords: Direct Attach Cable
Brand: SOPTO Port: Shenzhen Port
High Light:

underwater fiber optic cable

,

multimode fiber optic cable

Product Description

time-honored brand high speed cable 100G QSFP28 to QSFP28 1M AWG30 PVC

Product Description



       DAC Direct Attach Copper Cables are further divided into passive copper cable and active copper cable

In most data center, most server to server connections require 2-5 meters, while rack to rack connections are required to be connected by 8-12 meters cables.

      Passive copper cableare widely chosen by data centers for connecting servers to servers or servers  to the Top Of the Rack (TOR) switch as they are passive, consume zero power, have the lowest latency and cost-effective.

       Active copper cable, which is less expensive and can support  transmission up to 15 meters with low power consumption, can satisfy the regular interconnection requirement for distance and cooling in most data center.

       SOPTO offers a wide range of products for 0.5m to 15m lengths and in QSFP+, SFP+ form factors. The unique EEPROM technique has been used to ensure the DACs are compatible with different brands on the original switches and routers.

       SOPTO supplies various kinds of high-speed interconnect DAC cable assemblies including 10G SFP+ Cables, 40G QSFP+ Cables, and 100G QSFP28 Cables and so on. All of our direct attach cables can meet the ever-growing need to cost-effectively deliver more bandwidth, and can be customized to meet different requirements. length: from 0.5m to 10m. AWG:24,26,28,30 optional. We accept the customization.

 1m Dac Copper Cable , 100G QSFP28 Dac Cables Compliant With SFF-8431 MSA 0

Features

Lower Power Consumption

Compliant with SFF-8431 MSA

Replace optical transceiver for short distance

Active DAC can reach up to 15m



Applications

10G~100G Ethernet

Fibre channel

Data center and in-rack connection



Ordering Information



Part   No.

Description

SPH-SFP-Cx

1G SFP to SFP Passive DAC x Meters x=0.5,1,2,3...12 AWG30/28/24

SPH-SFP+Cx

10G SFP+ to SFP+ Passive DAC x Meters x=0.5,1,2,3 AWG30 ;

x=0.5,1,2,3...10 AWG28/24

SPH-SFP+ACx

10G SFP+ to SFP+ Active DAC x Meters x=1,2,3 AWG30;

x=1,2,3...10 AWG28; x=1,2,3...15 AWG24

SPH-QSFP+Cx

40G QSFP+ to QSFP+ Passive DAC x Meters x=1,2,3 AWG30; x=4,5 AWG28; x=1,2,3...7 AWG24

SPH-QSFP+ACx

40G QSFP+ to QSFP+ Active DAC x Meters x=1,2,3...10

SPH-Q/4SFP+Cx

40G QSFP+ to 4*SFP+ Passive DAC x=1,2,3 AWG30; x=4,5 AWG26

 x=7 AWG24

Note:

1. Default jacket material is PVC.

2. Default operating case temperature is 0 ~ 70. If you need -40 ~85 products, add T after Part Number .

1m Dac Copper Cable , 100G QSFP28 Dac Cables Compliant With SFF-8431 MSA 11m Dac Copper Cable , 100G QSFP28 Dac Cables Compliant With SFF-8431 MSA 2

Company Information

 1m Dac Copper Cable , 100G QSFP28 Dac Cables Compliant With SFF-8431 MSA 31m Dac Copper Cable , 100G QSFP28 Dac Cables Compliant With SFF-8431 MSA 4

Packaging & Shipping

 1m Dac Copper Cable , 100G QSFP28 Dac Cables Compliant With SFF-8431 MSA 5

Certifications

 1m Dac Copper Cable , 100G QSFP28 Dac Cables Compliant With SFF-8431 MSA 6

FAQ



1.Are you the real manufacturer?

Yes. Sopto is Group background. We are manufacturers of fiber cables, fiber, optic active and passive components, and PON equipment.

2.Do you offer Compatible Services?

Yes, we offer compatible service with Cisco, Nortel, Extreme, Foundry, Alcatel, Allied, HP, 3COM, Juniper, Enterasys....

3. Does sopto accept a small order?

Yes, it is available. Sopto support new projects of our customers and a long-term trustworthy relationship always starts from a small order.

4.What is your delivery time?

It depends on the quantity of the order. Normally we have them in stock, but for the busy season, it takes 1-3 working days.

5.What payment methods do you support?

The methods are followed: T/T, L/C, Western Union and PayPal.

6.Who are your main customers?

All our customers are valuable. We have more than 600 customers worldwide. China Telecom, China Mobile, China Unicom and SOHU are our main domestic customers.

1m Dac Copper Cable , 100G QSFP28 Dac Cables Compliant With SFF-8431 MSA 7
