Product Details:
|
|
| Brand Name: | Sopto |
|---|---|
| Certification: | ISO9001 / CE / RoHS |
| Model Number: | SPT-PXX8G-XD |
|
Payment & Shipping Terms:
|
|
| Delivery Time: | 3-5 working days |
| Payment Terms: | T/T; L/C; Paypal |
|
Detail Information |
|||
| Wavelength: | 850nm / 1310nm / 1550nm | Fiber Type: | SMF / MMF |
|---|---|---|---|
| Distance: | 300m(OM3) / 10m To 80km | Interface: | Duplex LC |
| Certification: | ISO9001 / CE / RoHS | Operating Temperature: | Commercial 0 To 70 Industrial -40 To 85 |
| High Light: | sfp transceiver single mode,fiber optic sfp module |
||
Product Description
Duplex LC Interface 8G SFP+ Fiber Optic Module with DDM RoHS-6 Compliant
SOPTO’s 8G FC SFP+ is a series of optical transceiver modules designed for use in 8G/16G Fiber Channel links. They are compliant with the SFP+ MSA. Digital diagnostics functions are available. The optical transceivers are RoHS compliant. Sopto supplies OEM service and Third-Party(Cisco, Juniper, HP, Dell etc.) compatible fiber optic transceivers.
Features
● RoHS-6 compliant
● Duplex LC Interface
● Low power dissipation
● Single +3.3V power supply
● Supports data rates up to 8.5Gb/s
● Built-in digital diagnostic functions
● Support Multi-rate for 8G/4G/2G/1G FC
● Transmission distance up to 100m on MMF OM3 and 80km over SMF
● Operating Case Temperature: Standard: 0~70°C; Extended: -20~85°C; Industrial: -40~85°C
Sopto fiber optic transceiver took the first lead to pass the ISO9001 quality system, the requirements of European CE, RoHs
Applications
● 8X/4X/2X/1X FC at 8.5/4.25/2.125/1.0625Gbps
Ordering Information
| PN | Data Rate (Gbps) | Distance | Fiber | Output Power(dBm) | Sensitivity(dBm) | Interface | Temp. | DDM |
| SPT-P858G-S3D | 8.5 | 300m/OM3 | MM | -5～-1 | -11 | Duplex LC | 0 to 70℃ | D |
| SFP-P138G-10D | 8.5 | 10km | SM | -5～0 | -15 | Duplex LC | 0 to 70℃ | D |
| SFP-P138G-20D | 8.5 | 20km | SM | -4～0 | -15 | Duplex LC | 0 to 70℃ | D |
| SPT-P558G-40D | 8.5 | 40km | SM | 0～3 | -17 | Duplex LC | 0 to 70℃ | D |
| SPT-P558G-60D | 8.5 | 60km | SM | 0～4 | -22 | Duplex LC | 0 to 70℃ | D |
|
SPT-P558G-80D |
8.5 | 80km | SM | 0～5 | -23 | Duplex LC | 0 to 70℃ | D |
